Automatic Sitting Machine for BOPP PE PVC Film Foil Fabric Roll Slitter Paper and Plastic Film Rewinding Machine

HAFA500 Can rewind aluminum foil /Baking paper /Cling film,it can make more than 1000m size .the min size can me 3m .The normal speed can run at 300m/minute Also we can customized for you.Welcome contact us!
Availability:
Quantity:
  • HAFA-500

  • FITLIFE

Thickness of Raw Material 9mic-20mic
Width of Raw Material 250-500mm
Maximun Unwinding Diameter D60mm
Inner Diameter of Raw Material Roll Core D75mm,D150mm
Inner Diameter of Finished Product Roll Core D32mm,D30mm,D35mm, D38 mm
Cutting Length of Roll 3-300m
Production Efficiency 150m/sec
Decoil Centering Stroke +/-20mm
Air Pressure 0.5Mpa
Engine Model Siemens panel, Mitsubishi servo , Mitsubishi PLC, Omron meter counter
Traction Motor Y100L-4
Asynchronous Motor 2.2Kw
Squirrel-cage Rotary Motor P60B 8200
Servo Motor 1.5Kw
Rotary Glue Motor 100YCJ120-3AP
Reduction Motor 120W
Magnetic Powder Brake 25N.m
Magnetic Powder Cluch 25N.m
Overal Dimension 1800mm*1600mm*800mm(L*W*H)
Total Power approx 4.5KW
Total Weight approx 1450Kg

Automatic Rewinder32Automatic Rewinder34Automatic Rewinder31Automatic Rewinder35
